Specs & Layout
|
Draft (Trimmed Down) | 32''
| | Length | 19' 5''
|
Average Hull Weight | 2500 lbs.
| | Beam | 8' 6''
|
Average Hull Weight W/Motor | 3135 lbs.
| | Bottom Width | 7' 2''
|
Average Package Weight | 4090 lbs.
| | Max. Recommended HP | 175 HP
|
Bridge Clearance | 3' 10''
| | Fuel Capacity | 40 gal.
|
Bridge Clearance W/Wakeboard Tower Upright | 7' 7''
| | Max. Person Capacity | 10 persons
|
Package Height | 6' 6''
| | Max. Person Weight | 1430 lbs.
|
Package Height W/Wakeboard Tower Upright | 10' 6''
| | Max. Person, Motor & Gear Weight | 1900 lbs.
|
Package Width | 8' 6''
| | Interior Depth | 32.5''
|
Towing Length | 26'
| | Deadrise | 20 degrees
|
Storage Length | 22' 6'' | | Draft (Trimmed Up) | 16.5''
|
|
Move pointer over boat to open/close compartments.
Features
COMFORT, CONVENIENCE & PEACE OF MIND
- NMMA® certified
- EPA-compliant fuel system
- Color-matched Bimini top w/boot, drop-down changing curtain & stainless steel frame w/quick-release hardware
- Stainless steel drink holders
- Stainless steel bow pull-up anchoring cleat
- 6 stainless steel pull-up mooring cleats
- Stainless steel passenger grab rails
- Aft 4-step boarding ladder
- Removable, solid aluminum ski tow pylon
- Fire extinguisher
- Horn
- Paddle
CONSOLE
- Acrylic windscreen
- Toggle switches
- Digital depth sounder
- Stereo w/Bluetooth®, MP3 & USB input & 4 speakers
- Sport steering wheel
- Mobile phone holder w/12V outlet
INTERIOR
- Non-skid finish on fiberglass floor
- Premium UV-resistant upholstery
- Wraparound bow lounge seating w/storage below
- Bow 11.5-gal. (43.53 L) aerated livewell w/500 GPH (1,892.71 LPH) pump, gravity drain, adjustable spray head & dash-mounted switch
- Port refreshment center w/storage
- KICKER® stereo w/Bluetooth®, MP3 & USB input & 4 speakers
- In-floor wakeboard/ski storage compartment w/hold-open lid assist
- Adjustable driver bucket seat w/slide, swivel & flip-up bolster
- Aft L-lounge w/storage, tow rope holder & removable 25-qt. (23.66 L) cooler
- Ski tow pylon storage
- Aft trash receptacle w/lid & removable insert
- Removable table w/2 mounting locations
- Walk-thru transom gate
PERFORMANCE
- POWERGLIDE® hull design w/reverse chine & HYDROSTEP® strakes for increased overall performance
- Factory-matched propeller
CONSTRUCTION & EXTERIOR
- 100% composite construction
- Hand-laid hull & stringer system for strength & durability
- Full-length fiberglass, foam-filled & gelcoat-finished stringer system bonded to the hull
- Hull & deck chemically bonded & mechanically fastened
- Closed-molded interior parts for lightweight, durable construction
ELECTRICAL
- 1,000 GPH (3,785.41 LPH) bilge pump w/automatic float switch
- Navigation lights w/LED bow lights & removable stern light
- LED interior courtesy lights
- Interstate® cranking battery & battery charger
- Automotive-style fuse panel w/circuit breaker-protected harness
- Water-resistant electrical connections on all pumps, courtesy lights & navigation lights
- 12V outlets
