2019
Fishin' Barge 24 XP3
Fishin' Barge 24 XP3
$61,995
- $2,000 (SPECIAL FINANCE CASH REBATE)
- $1,000 (2019 SUN CHECK CREDIT)
=$58,995

w/Mercury 150 L FourStroke
Boat, Motor, Tandem-Axle Trailer w/Brakes, and Cover - all included!

Canadian Price
$58,995 CAD or $233 Biwkly
Photos may show optional equipment.
Specs and features subject to change without notice.

Description

10+LIFE™ Limited Lifetime warranty

  • XP3 performance package w/three 26” (66.04 cm) logs w/lifting strakes
  • Built-in Rail-Lock™ system for optional snapless mooring cover
  • Bow fishing deck w/port 12-gal. (45.42 L) aerated livewell, starboard compartment prewired for optional fish package, 2 fishing chairs & rod, tool & drink holders
  • Console w/cooler storage below, NEW helm chair, stereo w/Bluetooth® & USB input & forward couch w/Stow More™ seat-back compartment & lockable underseat compartment
  • Color-keyed 9' (2.74 m) Bimini top w/QuickLift™ deployment system & storage pockets
  • Aft L-lounge w/underseat storage, base for removable table, Stow More™ seat-back compartment & pop-up changing curtain
  • Aft fishing deck w/16-gal. (60.57 L) aerated livewell, 2 fishing chairs, rod holders & convenient access to lounge-back-integrated compartments
  • NEW woven vinyl flooring
  • Aft boarding platform w/fold-down ladder

The impressively spacious and outfitted FISHIN’ BARGE 24 XP3 provides everything a crew of up to 12 people need to get off the land and onto the water for a day of fishing fun.

For one, it’s 26’ 2” long and 8’ 6” wide, providing more room for moving around while you work a fish. And speaking of fishing, it offers two fishing decks, each with rod storage, an aerated livewell and two fishing chairs. And when you’re not fishing, there’s more seating midship for lounging under the Bimini. Underseat storage and the Stow More seat-back storage offer more spaces for stowing all the gear.

And thanks to the three-log XP3 package, the FISHIN’ BARGE 24 XP3 is rated for up to 250-horsepower, providing more performance for cruising and watersports. All for more memory making!



Specs & Layout

SpecificationsSpecifications
Max. person, motor & gear weight3000 lbs.  Length26' 2''
Interior depth24"  Deck length24' 1''
Average dry weight2960 lbs.  Deck width8' 6''
Average package weight5284 lbs.  Max. recommended HP250 HP
Package height9' 1''  Fuel capacity52 gal.
Package width8' 6''  Pontoon log length24' 11''
Towing length34' 6''  Pontoon log diameter26"
Storage length34' 6''  Max. person capacity12 persons
 Max. person weight2100 lbs.

Move pointer over boat to open/close compartments.

Features

Standard Features
Comfort, Convenience & Peace of Mind
  • NMMA® certified
  • 9' (2.74 m) color-keyed Bimini top w/LED courtesy lights & protective boot
  • NEW front zipper on Bimini top to join optional double Bimini together
  • Storage pockets in Bimini top
  • Adjustable nylon pull-tight Bimini straps for quick adjustment & reduced vibration
  • NEW nylon gate latches & heavy-duty hinges that open inward
  • Port & starboard LED navigation lights
  • Bimini-mounted anchor/navigation light
  • 4 mooring cleats
  • Motor-stop safety lanyard
  • Fire extinguisher
  • Horn
Livewell Systems
  • Bow port 12-gal. (45.42 L) rotomolded & aerated livewell w/shutoff valve & composite lid w/ruler
  • Aft port 16-gal. (60.57 L) aerated livewell w/removable bait bucket & shutoff valve
Console
  • Deluxe soft-touch sport steering wheel
  • Hydraulic steering w/tilt
  • Wraparound sport console shroud & tinted, removable windscreen
  • Below-console cooler/storage space w/door & integrated pouch
  • Small items tray
  • Drink holders
  • Built-in footrest w/non-skid pad
  • AM/FM Bluetooth®-capable stereo w/MP3 & USB ports & 2 directional speakers
  • Tachometer, trim meter/speedometer & fuel & hour gauges
  • Lighted rocker switches
  • Ergonomically positioned Mercury® binnacle control box w/trim
  • 12V outlet
Interior
  • Port bow rotomolded box w/livewell, ruler & drink holders
  • Starboard bow rotomolded box w/storage, ruler & drink holders
  • Clam-shell fishing chairs constructed w/all-composite seat frames w/heavy-duty 2-3/8" (6 cm) diameter pedestals
  • Bow & aft fishing positions w/4 removable folding fishing chairs
  • Forward-console couch w/Stow More™ system & underseat storage
  • Aft L-lounge w/Stow More™ system, underseat storage & lockable storage compartment
  • Rear-facing tackle storage in aft L-lounge
  • NEW high-back swiveling helm bucket seat, reclining & w/self-leveling arms
  • Pop-up changing room in lounge arm
  • Fore & aft vertical rod holders
  • Molded starboard aft lockable rod box for rods to 7' 6" (2.29 m)
  • Padded woven vinyl floor covering
  • Marine-grade, UV-resistant, top-coated upholstery w/26-oz. (.74 kg) base material & multiple densities of foam
  • Movable drink holder/armrest
  • NEW removable table w/padded insert, 4 molded-in drink holders & 2 pedestal base locations
  • Port wheelchair-access gate
  • 4-step folding boarding ladder w/grab rails
Performance
  • XP3 performance package – strakes on inboard side of outer logs & both sides of center tube
  • Nose cone & motor pod wave/spray deflectors for a drier ride
  • Factory-matched aluminum propeller
Construction & Exterior
  • NEW interior styling
  • Rotomolded furniture backs & bases for resistance to the elements
  • Heavy-duty bow U-channel reinforcement behind deck trim
  • Three 26" (66.04 cm) diameter XP3 high-performance multichambered pontoon logs w/welded-on lifting strakes & internal bracing for additional strength
  • 1-piece full-length M-bracket deck supports
  • Rail-Lock™ system for mounting optional snapless, trailerable mooring cover w/removable bow extension
  • Protective exoskeleton rail & panel system for durability & a quieter ride
  • High-sheen fence finish for long-lasting good looks
  • 1-1/4" (3.18 cm), .090" (.23 cm) thick anodized aluminum fence rails w/decorative styling
  • Factory-installed underpinning (under-deck shielding) for improved performance
  • Extruded anodized aluminum deck edging w/polished aft corner covers
  • All-welded, all-aluminum extended motor pod w/built-in EPA-compliant fuel system
  • Stainless or coated corrosion-resistant fasteners
  • 7-ply pressure-treated 3/4" (1.91 cm) deck w/Limited Lifetime Warranty
  • Full-width heavy-duty extruded Z-bar deck supports that are thru-bolted to M-brackets
  • Elevated fence panels for deck drainage & ventilation
  • Sound- & vibration-deadening fence insulation for a quiet ride
  • Box-beam all-aluminum transom for strength & longevity
  • Rear boarding platform
  • Black Metallic or Caribou Metallic fence color
Electrical
  • Easy-access marine-grade automotive-style fuse panel w/NEW latching fuse block door
  • Protective abrasion-resistant wire wrap
  • Water-resistant connectors
  • Interior courtesy lighting
