2020
OX400
OX400
$8,699
-$1,000 (SPECIAL FINANCE CASH REBATE)
=$7,699

401 cc (13.5 hp) Single-Cylinder, 4-Cycle, Air-Cooled Engine with EFI
Automatic, Continuously Variable Transmission (CVT)
Closed-Loop Electronic Fuel Injection
Electronic Inductive Spark Ignition
Canadian Price
Photos may show optional equipment.
Specs and features subject to change without notice.

Description

BIG MUSCLE MEETS BIG VALUE.

Introducing OX400, the latest, hard-working, no-nonsense UTV from TRACKER Off Road. This rugged 401 cc machine capably delivers 1,200 lb towing capacity, 500 lb bed load capacity and the type of long-haul dependability you’ve come to expect from TRACKER.

KEY FEATURES

  • 13.5 hp, 401 cc single cylinder, air-cooled engine
  • Overhead valve
  • Pressurized oil system, spin-on oil filter
  • Internal counter rotating balance shaft
  • Closed-loop electronic fuel injection
  • Electronic inductive spark ignition
  • Replaceable dry cartridge air cleaner
  • Electrical Starter/Generator, solid-state regulator, 12 Volt maintenance free HD battery (700 CCA, 95 minute reserve)
  • Automatic, continuously variable transmission (CVT)
  • Dual rear wheel mechanical self-adjusting drum brakes. Single point park brake release with self-compensating system
  • Transaxle differential with helical gears, ground speed governor, forward/reverse
  • Roto-molded cross-linked polyethelene cargo bed. Lifts for access to powertrain. Removable hinged tailgate

Specs & Layout

SpecificationsSpecifications
DrivetrainCVT (Continuously Variable Transmission)  Overall Length119 in (302 cm)
TransaxleDifferential with Helical Gears  Overall Width51.5 in (131 cm)
Gear SelectionForward-Reverse  Overall Height w/o Canopy53 in (135 cm)
Rear Axle Ratio11.47:1 (Forward) 14.35:1 (Reverse)  Overall Height w/ Canopy77 in (196 cm)
Seating Capacity2 Passenger  Wheelbase77.5 in (197 cm)
Dry Weight w/o Batteries1,032 lb (468 kg)  Front Wheel Track44 in (112 cm)
Curb Weight1,072 lb (486 kg)  Rear Wheel Track46 in (117 cm)
Vehicle Load Capacity900 lb (408 kg)  Ground Clearance @ Differential7.0 in (18 cm)
Outside Clearance Circle23.5 ft (7.2 m)  Bed Dimensions44 x 39 x 12 in (112 x 99 x 30 cm)
Speed (Level Ground)16.5 mph ± 0.5 mph (26.58 kph ± 0.8 kph)  Power Source401 cc single cylinder, 4 stroke, gas
Bed Load Capacity500 lb (227 kg)  Valve TrainSingle-Cylinder OHV
Tow Capacity1,200 lb (544 kg)  Fuel SystemClosed-loop electronic fuel injection
SteeringSelf-compensating reduction rack and pinion  Horsepower (KW)13.5 hp
SuspensionLeaf Springs with Hydraulic Shock Absorbers  Electrical SystemStarter/Generator — Solid State Regulator
Rear SuspensionMultiple-Leaf Springs With Hydraulic Shocks  Batteries (Qty/Type)One, 12V Maintenance Free
Service BrakeRear Wheel Mechanical Self-Adjusting Drum  Key or Pedal StartPedal
Parking BrakeSelf-Compensating, Single Point Engagement  Air CleanerIndustrial Rated Dry Filter
Tires23 x 10 - 12 (4 Ply Rated)  LubricationPressurized Oil System
FrameWelded steel. DuraShield™ powder coat  Oil FilterSpin-On
Body & FinishInjection Molded TPO  Cooling SystemAir Cooled
COLOR OPTIONSBlack Fuel Capacity6.65 gal (25 L) Tank

Move pointer over boat to open/close compartments.

Videos & Photos

Videos

Features

Warranty 2 Years



    Additional Accessories

    Hauls All PACKAGE
    • Split Windshield Kit
    • Rearview Mirror
    • Mesh Net Cover
    • 4-Corner D-Ring Kit
    Package Price: $1,539.00 CAD
